Jordan
Jordan Specifications
| Engine | Honda RA001E |
| Type of Engine | V10 Normal Aspiration |
| Capacity | 3.0 Litres |
| Brake Horsepower | Over 800ps |
| Max Revs | In Excess of 17,000 rpm |
| Cylinder Heads | 4 Valves per Cylinder |
| Valve System | Pneumatic |
| Injection System | Honda PGM-FI |
| Ignition System | Honda PGM-IG |
| Spark Plugs | NGK |
Car Specifications
| Chassis | Full carbon fibre composite monocoque |
| Front Suspension | Composite pushrods activating chassis mounted Penske dampers and torsion bars, unequal length aerodynamic wishbones, composite top and bottom wishbones, titanium fabricated uprights and front anti-roll bar. |
| Rear Suspension | Composite pushrods activating gearbox mounted Penske dampers, unequal length aerodynamic wishbones, composite wishbone, titanium fabricated uprights and rear anti-roll bar. |
| Transmission In house Jordan GP design. | 7 speed + reverse longitudinal gearbox with electrohydraulic sequential gear change. |
| Wheel Base | Over 3000mm |
| Front Track | 1500mm |
| Rear Track | 1418mm |
| Overall Height | 950mm |
| Overall Length | 4650mm |
| Overall Weight | 600kg with driver |
| Clutch | Triple plate Jordan/Sacks racing clutch |
| Brakes | Brembo brake calipers and Brembo and Hitco carbon fibre discs |
| Wheels | Forged OZ racing to Jordan GP specificationorged OZ racing to Jordan GP specification |
| Tyres | Bridgestone |
| Fuel Tank Capacity | Over 100kg |
Sponsorship
| Benson & Hedges, Bridgestone, Deutsche Post World Net, Infineon, Mastercard, Lucent Technologies, LeggMason, Brother International, Imation, Hewlett Packard, World of Internet, Puma, Esat Digifone, Powermarque, Grundig, OMP, Laurent-Perrier |
